Versa Pump base – Ecotech Marine

Product details

Versa Pump base – Ecotech Marine is a peristaltic pump base station setup designed to let Versa pumps work together from a single power supply. Peristaltic pumping is commonly used in reef systems where precise, repeatable liquid transfer is needed—such as dosing small amounts, auto-top-off (ATO), automated water changes, and other timed routines. Versa uses a stepper motor with a planetary drive for controlled output, and can be calibrated and programmed using EcoTech Marine’s Mobius app for phone/tablet control.

Features:

• Base station setup allows Versa pumps to work together and be powered by a single power supply
• Peristaltic design supports accurate, repeatable transfer across a wide volumetric range
• DC stepper motor with planetary drive for consistent and reliable operation
• Onboard Bluetooth and Mobius control enable quick calibration and flexible scheduling
• Supports continuous dosing or discrete dosing points (up to 30) in Mobius
• Includes tactile pump button(s) on the base station for manual dosing or priming
• Designed for modular use: individual pumps can be added to a base station if purchased separately

Specifications:

• Dosing volume range: .5 µL/min to 300 mL/min
• Accuracy: ±0.2 mL for quantities of 1 mL or less; ±1% for quantities of 1–300 mL (2% advertised)
• Input voltage: 110–220V
• Vertical head pressure: 18+ ft (6 m)
• Connector options: ¼” stem (push-to-connect accessory), ¼” female (push-to-connect), or ¼” barb (soft-wall tubing) for barb fitting
• Tubing: ¼” OD polyethylene-style tubing (push-to-connect) or ¼” OD soft-wall tubing (barb fitting)
• Pump footprint (without connector): 3.45” x 3.15” x 2.34”
• Base station footprint (no pumps): 12.80” x 3.52” x 1.51”
• Control software compatibility: Controllable exclusively with Mobius; not backwards compatible with EcoSmart Live
• Warranty: 1 Year Parts and Labor EcoTech Warranty
