Hydros Control X10 – Coralvue

Product details

Hydros Control X10 – Coralvue is a compact aquarium controller designed to monitor key water parameters and manage dosing/outputs as part of a HYDROS system. Used as a standalone controller, it can support saltwater aquariums, freshwater tanks, and pond applications; or it can be expanded by integrating additional HYDROS Controls for a larger, coordinated setup.

Features:

• Monitor and control water conditions while supporting broader HYDROS system expansion
• Includes dedicated connection points such as one (1) Salinity Probe Port and a pH/ORP Port
• Offers multiple Sense Ports for additional input monitoring
• Provides two (2) Drive Ports to power connected HYDROS components (up to the device limits)
• Built-in four (4) stepper dosing pumps for independent fluid metering
• Internal health monitoring reports device voltages, currents, CPU status, and internal temperature
• Engineered, assembled, and supported in the USA

Specifications:

• Dimensions (L x W x H): 7.75″ x 6.75″ x 4.25″
• Salinity Probe Port: 1
• Sense Ports: 4
• Drive Ports: 2
• pH/ORP Port: 1
• Command Bus: Included
• Stepper dosing pumps: 4 independent pumps
• Pump speed range: -100 mL/min to 100 mL/min
• Current handling per drive port: Up to 1A per drive port
• Total device current limit: Up to 1.5A total
• Processor: Fast dual-core 32-bit processor
• Internal monitoring: Reports voltages, currents, CPU status, and internal device temperature
