Entry M25 RDF Combi + MAT Chamber ( NEW ) – Sea Side Aquatics

Product details

Entry M25 RDF Combi + MAT Chamber ( NEW ) – Sea Side Aquatics is a gravity- and pump-fed aquarium filtration unit designed to mechanically remove debris via a 120 micron stainless steel sieve panel and drum cleaning system. It combines an RDF (rotary drum filter) section with a MAT-style media chamber for biological filtration, using Helix and Japanese Mats/Matala Mat media areas as indicated in the supplied setup. In practical use, it helps keep aquarium and pond systems clearer by automatically rinsing the drum and flushing collected waste, while the MAT/media chambers provide space for beneficial biological growth. The included control options support automated cleaning cycles as well as manual turn/rinse control, making the unit suitable for installations where consistent mechanical cleaning and biological filtration are both needed.

Features:

• Automatic plug-and-play cleaning using a stainless steel float control (with adjustable turn/flush timing and adjustable rinse level)
• RDF drum with 120 micron stainless steel 316 sieve panel for mechanical debris separation
• Configured for gravity and pump feeding, supporting installations with flexible plumbing and flow paths
• Demountable spray bar, removable flushing channel, and modular parts for faster interchange
• Bio chamber support for 90 liters of Helix plus separate guidance for Japanese Mats/Matala Mat-style media
• Includes 2 x air bars to support media aeration as part of the bio chamber setup
• Control box includes sockets for flushing pump, pond pump, and drum drive motor, with standard dry-run protection for the pond pump

Specifications:

• Maximum flow: 25 m3 / h
• Installation height above water level: 16 cm
• Waste water outlet: 1 x 110 mm
• Drum diameter: 38 cm x 40 cm
• Sieve panel: 120 micron stainless steel 316
• Drum bypass: 2 x 90 mm
• Motor: 40 NM drive motor with 2.5 rpm
• Inlets / outlets (connection size): 3 x 4" Inlets and 2 x 4" Outlet
• Housing materials: PP 8 mm / PP15 mm / Drum PP 20; stainless steel 316/304; silicone seal
• Additional: With a lid; CE quality mark; supplied with comprehensive manual
