D50 Wifi Version RDF – Sea Side Aquatics

Product details

D50 Wifi Version RDF – Sea Side Aquatics is a WiFi-enabled digital controller and system unit designed for automatic waste management using an external cleaning pump (installation required). In practical aquarium use, it supports a recurring cleaning cycle and waste tray wash function to help manage debris from your setup. The unit is built for plug-and-play control with a float switch and includes adjustable cleaning timing and cleaning level, helping you standardize routine maintenance without manual turn/wash cycles.

Features:

• WiFi included for digital control/monitoring (instruction support via WiFi version documentation)
• External cleaning pump included; required installation
• Force cleaning included for manual or controlled cleaning actions
• Automatic waste tray wash included
• Automatic cleaning is plug and play with a float switch
• Cleaning (turn/flushing) time is adjustable, and cleaning level is adjustable
• Modular internal components built into quickly changeable modules
• Dry-run protection for the pond pump is included; CE approved

Specifications:

• Maximum flow: 50 m3/h (approximately 13,200 GPH)
• Operating pump feeding options: Gravity / Airlift / Pump feed
• Pump version note: Pump Version has 30% less capacity
• Water running height: 12 cm
• Housing materials: PP (10/15 mm housing), drum PP (20/15 mm); RVS 316/304; silicone sealant
• Mesh: Patented woven 75 micron steel mesh
• Inlets: 4 × 110 mm inlets
• Outlets: 4 × 110 mm outlets
• Waste outlet: 1 × 110 mm waste outlet
• Extra inlet: 1 × 50 mm extra inlet
• Drum size: Diameter 60 cm × 40 cm
• Drum bypass: 2 × 90 mm drum-by-pass
• Drive: 40 NM drive engine with 2.5 RPM
• Control panel: Siemens LOGO PLC control panel
• CE approved: Yes
• Control options: 3 plugs to control Drum, Cleaning and Pond-pump
• Cover: Comes with cover
