45481 Loc-Line Acid Resistant Swivel Nozzle 40 for 1/4″ ID System, pack of 2

Product details

The 45481 Loc-Line Acid Resistant Swivel Nozzle 40 for 1/4" ID System, pack of 2 is a specialized modular nozzle designed for fluid dispensing applications in acidic environments. Constructed from polyester material, these nozzles feature a ball and socket design that allows full hand adjustment of position and length, making them ideal for precise rinsing cycles in industrial plating operations and similar processes where acid resistance is essential.

Features:

• Constructed from acid-resistant polyester material compatible with acids under 150°F, alcohols, aromatic solvents, gasoline, grease, hydrocarbons, oils, and salt
• Features 0.040-inch hole diameter for fine spray patterns and controlled fluid delivery
• Ball and socket design allows fully hand-adjustable positioning and length adjustment
• Yellow color for easy identification
• Electrically non-conductive design suitable for sensitive industrial applications
• Operates at 50 PSI and 250 GPH maximum flow with 1/4" hose system, or up to 110 PSI and 500 GPH when used with element clamps

Specifications:

• Material: Polyester
• Nozzle Hole Diameter: 0.040 inches
• Hose System Compatibility: 1/4" ID (inside diameter)
• Color: Yellow
• Maximum Operating Pressure: 50 PSI (or 110 PSI with element clamps)
• Maximum Flow Rate: 250 GPH (or 500 GPH with element clamps)
• Maximum Operating Temperature: 170°F continuous; 150°F recommended for acid applications
• Package Quantity: Pack of 2
