CL65-L RDF + Bio Chambers WIFI Controller – Sea Side Aquatics

This is our newest wifi / digital controller that only with with 2 probe sensor and with other add on options like:

Wifi ( Included )
SMS message ( Not Included )
Temperature ( Not Included )
Water Level Sensor ( Not Included )
Water Top Off ( Not Included )
Force Cleaning ( Included )
Automatic Waste Tray Wash ( Included )
and many more features please click on the below link to have access to the pdf files

Wifi Version Instruction
Technical details
CL65-L
Maximum Flow 65 m3/h
Gravity / Airlift / Pump feed
Pump Version has 30% less capacity
Water running height 12 cm
Material:
Housing PP 10/15 mm / Drum PP 15 mm
RVS 316/304 / UV resistant Seal
Precise CNC machine cut PP-construction
Specifications:
Standard inputs and outputs acc. drawing
Changes to inputs and outputs possible
1 x 110 mm Waste Outlet
Diameter of drum 60 cm x 50 cm
Patented woven 75/120 micron stainless steel mesh
2 x 90 mm Drum-Bypass
Removable spraybar
Removable waste water gutter / Waste claening optional
Installed Cleaningpump 5 Bar
50 NM drive engin with 4 RPM
With Lid
CL65L
2 Built-in air disc of 35 cm
Moving bed for 200 liter
helix Moving bed for 200 liter helix
Wifi Digital Control panel:
Automatic cleaning, plug and play with Sensor
Manual operation run/wash
Cleaning (turn/flushing) time adjustable
Cleaning level adjustable
3 plugs to have control over Drum filter motor, Cleaning and Pond-pump
Standard dry run protection for pond pump
All components built into modules wich quickly changeable
Comes with detailed instructions
CE approved
