Mean Well LDD-300H dimmable driver

Features

DC to DC constant current driver for driving ~1-15 x 3V LEDs (depending on your power supply and LEDs). Output voltage is always 2-3V less than input voltage �These drivers will require a DC power supply unlike the Meanwell�HLG or LPC driversComes with pins for easier installation on the�LDD-H-4S board. We suggest using this over the standard LDD-H-4 board as the dimming pin�will not work on the LDD-H-4Capable of dimming down to 1% using a PWM controller

Specifications

SKU :�LDD-300HOutput Voltage (DC) :�2-46V (Output Range Will Always Be 3V Lower Than Input)Max Output Current :�300mAInput Voltage (DC) :�9-52VDimming Signal :�2.5-6V PWMEfficiency :�97% At Full LoadDimensions :�1.25″ X 0.8″ X 0.48″Weight : 15.6g

Instructions

Mean Well LDD-H Series Datasheet
