Mean Well LDD-350H dimmable driver

Features

DC to DC constant current driver for driving ~1-15 x 3V LEDs (depending on your power supply and LEDs). Output voltage is always 2-3V less than input voltage �These drivers will require a DC power supply unlike the Meanwell�HLG�or LPC driversComes with pins for easier installation on the LDD-H-4 or�LDD-H-4S boardCapable of dimming down to 1% using a PWM controller

Specifications

SKU :�LDD-350HOutput Voltage (DC) :�2-52V (Output Range Will Always Be 3V Lower Than Input)Max Output Current :�350mAInput Voltage (DC) :�9 ~ 56VDCDimming Signal :�2.5-6V PWMEfficiency :�97% At Full LoadDimensions :�1.25″ X 0.8″ X 0.48″Weight :�15.6g�

Instructions

Mean Well LDD-H Series Datasheet
